CC-Link Slip Rings
A CC-Link slip ring is a specialized electromechanical component designed to transmit CC-Link industrial network data and power across rotating interfaces. It ensures real-time, high-speed communicationthrough enhanced shielding and low-noise contact technology while supporting continuous 360° rotation. The device making it critical for industrial automation systems, robotic workcells, semiconductor manufacturing equipment, and other applications requiring reliable network communication under continuous rotation conditions.
| Model Code | Voltage | Outer Diameter(mm) | Circuits | Inner Diameter (mm) | Length(mm) | Special Signal Channel | Normal Signals | Special signals (U2, U3, SDI, E2, E3、HD-SDI) | Standard signals (CAN/CANbus, Profibus, RS422/485, CC-Link, DeviceNet, etc.) | CC-Link channels |
|---|---|---|---|---|---|---|---|---|---|---|
| LPC-D30-1501-01S | / | Φ30 | 30 | 0 | / | / | / | / | / | 1 |
| LPC-D39-20S-05E3 | 0~24VAC/DC | ∅39 | 39 | 0 | 140.5 | 5 | 0 | Gigabit Ethernet | / | 4 |
| TMC-LPC-76A | 0~240VAC | ∅35.5 | 0 | 0 | 105.7 | 3 | / | Fast Ethernet、Gigabit Ethernet | / | 2 |
| LPT400-0730-04S | 0~400VAC | ∅660 | 7*30A | Φ 400 | 321 | / | / | / | / | 1 |
