DisplayPort Slip Rings
Engineered for high-bandwidth digital video transmission, JINPAT's DisplayPort Slip Rings deliver uncompromising signal fidelity with support for resolutions up to 8K UHD. They are ideally suited for industrial imaging systems, simulation equipment, and next-generation display monitors requiring flawless performance under continuous rotation. The robust design guarantees stable, high-speed data transfer across the rotary interface, while customizable auxiliary channels—including USB, power, and Ethernet—can be integrated to create a unified solution for complex applications.
| Model Code | DP1.0 | DP1.2 | Voltage | Outer Diameter(mm) | Circuits | Length(mm) | Supports Other Signal Types |
|---|---|---|---|---|---|---|---|
| LPM-30-DP | / | 1 | 0~110V | ∅16 | / | 37 | / |
| LPC-36A-01DP | / | 1 | 0~220V | ∅22 | / | 57.3 | / |
| LPC-12YT-01U3-01DP | 1 | / | 0~220V | ∅24.8 | / | 74.5 | 1* USB3.0 |
| LPC-0202-01U3-01DP | 2 | / | 0~220V | ∅25 | 2*2A | 86 | 1* USB3.0 |
| LPC-12T-0202-01U2-DP | 1 | / | 0~220V | ∅24.8 | 2*2A | 74 | 1* USB3.0 |
| LPC-24YT-0902-01U3-01DP | 3 | / | 0~220V | ∅25 | 9*2A | 88.3 | 1* USB3.0 |
