HDMI Slip Rings
Our HDMI Slip Rings deliver seamless transmission of uncompressed high-definition video and multi-channel audio, supporting HDMI 1.4 to HDMI 2.0 standards with resolutions up to 4K@60Hz. Designed for applications such as multimedia systems, medical imaging equipment, and interactive displays, they feature low crosstalk, high signal integrity, and flexible mounting options, with additional support for integrated power and control signals.
| Model Code | HDMI1.2 | HDMI1.4 | HDMI2.0 | Voltage | Outer Diameter(mm) | Circuits | Length(mm) | Supports Other Signal Types |
|---|---|---|---|---|---|---|---|---|
| LPC-36A-10S-HDMI-U2 | 1 | / | / | 0~220V | ∅22 | / | 57.3 | 1*USB2.0 10* Common Signal |
| LPM-30B-HDMI-U2 | / | 1 | / | 0~110V | ∅16 | / | 37 | 1*USB2.0 |
| LPM-30B-01HD | / | 1 | / | 0~110V | ∅16 | / | 37 | / |
| LPM-18-0601-02SDLPM-30-01HD | / | / | 1 | 0~110V | ∅16 | / | 37 | / |
