Through-hole, multi-channel: JINPAT LPT slip rings powering automation equipment

Within the realm of modern industrial automation, such as in robotic systems, CNC machining centres, and rotary tables, the stable transmission of power and signals to continuously rotating components presents a significant technical challenge. The JINPAT LPT series hollow shaft slip rings are specifically engineered to address this issue. They resolve electrical connectivity between rotating and stationary parts of equipment, preventing cable entanglement while ensuring unlimited continuous rotation. This enhances the reliability and production efficiency of automated systems.

The LPT series slip rings combine multiple practical features to meet the demanding requirements of automation applications:

1. Large-diameter through-holes and compact structure: Featuring a 38mm diameter through-hole, it provides ample space for routing pneumatic lines, hydraulic lines, or other cable harnesses. Its overall compact design (99mm diameter, 131.7mm length) facilitates easy integration and installation within confined equipment spaces.

2. Highly integrated hybrid transmission: Innovatively combines 8 high-current pathways rated at 15A with 16 encoder signal pathways, plus 3 additional shielded channels. This hybrid design simultaneously fulfils the power demands of drive units and the high-frequency signal requirements of control units, significantly simplifying system architecture.

3. Superior Electromagnetic Shielding and Environmental Adaptability: The housing undergoes conductive white oxidation treatment, enhancing surface corrosion resistance while forming an efficient electromagnetic shielding layer. This significantly reduces internal and external electromagnetic interference, ensuring transmission quality for sensitive signals such as encoder data. Concurrently, the IP50 protection rating effectively prevents dust ingress, while the broad operating temperature range of -20°C to +60°C guarantees stable performance across most industrial environments.

In summary, the JINPAT LPT hollow shaft slip ring, with its large through-holes, multi-channel integration and superior shielding performance, stands as the ideal solution for addressing rotational connection challenges in automated equipment. Its application effectively enhances the overall performance and reliability of machinery, serving as a dependable partner in driving precision automation systems towards greater efficiency and intelligent operation.
