Powering immersive entertainment systems, this 2.6-meter modular High Current Slip Ring LPA000-14500-1250-0902-02E3 slip ring supports500A~ 2,000A current and 10kV voltage for large-scale rides like 5D theaters, Ferris wheels, and dynamic simulators. Its customizable multi-path design integrates power, control signals, and fiber optics, enabling 360° seamless rotation for lifelike motion effects. Featuring aerospace-grade insulation and fail-safe thermal management, it ensures uninterrupted operation under peak loads while meeting global amusement safety certifications. Perfect for theme parks seeking cutting-edge, high-thrill attractions.
Electronic & Electric |
Mechanical | |||
Circuits |
Total |
26 |
Working Speed |
0~15RPM |
Detail |
14*500A+12*50A |
Bore Diameter |
/ |
|
Rating Voltage |
380VAC |
Contact Material |
Imported Copper Graphite/Precious Metal |
|
Dielectric Strength |
1500VAC@50Hz |
Housing |
Q235 |
|
Insulation Resistance |
≥500MΩ@1000VDC |
Installation |
Vertical Installation |
|
Environment |
Remarks | |||
Working Temperature |
-10°C~+80°C |
Application |
large-scale rides |
|
IP |
IP51 |
Other |
/ |
|
Signal Channel Parameters | ||||
Rated current |
10*2A/22 sets of network cables (18 channels) |
Contact Material |
Alloy Brush Wire |
|
Rating Voltage |
380VAC |
Maintainability |
Maintenance-free |
|
Dielectric Strength |
300VAC@50Hz | Insulation Resistance | ≥100MΩ@300VDC | |
| Model Code |
|---|
