Built to endure offshore drilling rigs’ brutal conditions, this High Current Slip Ring LPA000-04500-01PE-0310-1005 features vibration-dampened contacts and IP66-rated anti-corrosive housing to resist seawater, oil mist, and constant platform shocks. It transmits power, digital/analog signals, and vessel control data with <0.1dB signal loss, even during hurricane-force vibrations. The quick-disconnect brush cartridge system enables onboard maintenance without crane disassembly, minimizing downtime in round-the-clock operations. Certified for Zone 1 hazardous areas, it’s vital for oil/gas platforms, wind farm installations, and heavy-lift marine operations.
Electronic & Electric |
Mechanical | |||
Circuits |
Total |
4+1 |
Working Speed |
1~10RPM |
Detail |
4*500A+1*PE |
Bore Diameter |
/ |
|
Rating Voltage |
380VAC |
Contact Material |
Copper Graphite/Precious Metal |
|
Dielectric Strength |
2500VAC@50Hz |
Housing |
Q235 |
|
Insulation Resistance |
≥500MΩ@1000VDC |
Maintainability |
Regular maintenance |
|
Environment |
Remarks | |||
Working Temperature |
-10°C~+40°C |
Application |
Offshore Platform Crane |
|
IP |
IP44 | Other | / | |
Signal Parameter | ||||
Rated Voltage |
230VAC |
Dielectric Strength |
500VAC@50Hz |
|
Rated Current |
3*10A+10*5A |
Insulation Resistance |
≥500MΩ@500VDC |
|
Contact Material |
Alloy Brush Wire |
Maintainability |
Maintenance-Free |
|
| Model Code |
|---|
