Designed for precision and stability, the High-Frequency Coaxial Cable Series and its auxiliary cables support critical applications in aerospace, electronic countermeasures, RF testing environments, and next-generation 5G communications.
| Product specification |
| Interface Type |
N-F/NM(75Ω) |
Body Materials |
BRASS |
| Frequency range |
DC-12GHz |
Insulator Material |
PTFE |
| VSWR,Max |
1.3 |
Durability |
＞500cycles |
| Insertion loss,Max |
1.0dB |
Operation Temperature |
-30~+75°C |
| Voltage rating |
250V(rms) |
Storage Temperature |
-30~+75°C |
|
Dielectric withstanding
voltage
|
1000V |
Humidity(Operation) |
95% |
| Insulation resistance |
5000MΩ |
Humidity(Storage) |
95% |
E18L-NFNM-01.00M Product Outline Diagram
