The High-Frequency Phase-Stable Coaxial Cable Series minimizes signal loss and interference, making it ideal for aerospace systems, electronic warfare applications, high-frequency shielding environments, and 5G infrastructure.
| Product specification |
| Interface Type |
N-F/N-M(50Ω) |
Body Materials |
Stainless steel/Brass/Be-Cu/PTFE |
| Frequency range |
DC-40GHz |
Plating |
Passivation/Gold |
| VSWR,Max |
1.3 |
Durability |
≥500cycles |
| Insertion loss,Max |
3.35dB |
Temperature range |
﹣40~+85°C |
| Voltage rating |
335V(rms) |
RoHS 2002/95/EC |
Compliant |
| Dielectric withstanding voltage |
500V |
Coupling nut retention |
＞60lbs |
| Insulation resistance |
3000MΩ |
Min.bending radius，dynamic |
60mm |
E40-29M29M-01.00M Product Outline Diagram
