Optimized for high-performance RF connectivity, the High-Frequency Coaxial Cable Series and its auxiliaries ensure phase stability and low attenuation in aerospace, electronic countermeasures, RF shielding, and 5G communication technologies.
| Product specification |
| Interface Type |
N-F/N-M(50Ω) |
Body Materials |
Stainless steel/Brass/Be-Cu/PTFE |
| Frequency range |
DC-18GHz |
Plating |
Passivation/Gold |
| VSWR,Max |
1.3 |
Durability |
≥500cycles |
| Insertion loss,Max |
0.98dB |
Temperature range |
﹣40~+85°C |
| Voltage rating |
335V(rms) |
RoHS 2002/95/EC |
Compliant |
| Dielectric withstanding voltage |
500V |
Coupling nut retention |
＞100lbs |
| Insulation resistance |
5000MΩ |
Min.bending radius，dynamic |
110mm |
SMA-M-SMA-F-RG178-500mm Product Outline Diagram
