CAN/RS422/485 Slip Rings
CAN/RS422/485 slip rings are specialized electromechanical devices designed to transmit industrial communication signals (CAN bus, RS422, RS485) and power across rotating interfaces. They employ robust shielding and precision contact technology to ensure anti-interference data transmission while supporting continuous 360° rotation. These slip rings maintain protocol integrity for multi-node serial communication, making them important for industrial automation, motion control systems, robotic swivels, wind power equipment, and other applications requiring reliable data exchange in rotating environments.
| Model Code | Voltage | Outer Diameter(mm) | Circuits | Inner Diameter (mm) | Length(mm) | Special Signal Channel | Normal Signals | Special signals (U2, U3, SDI, E2, E3、HD-SDI) | Standard signals (CAN/CANbus, Profibus, RS422/485, CC-Link, DeviceNet, etc.) | CAN/RS422/485 channels |
|---|---|---|---|---|---|---|---|---|---|---|
| LPC-18-0306-0602-01S | 0~380AC/DC | ∅22 | 18 | 0 | 42.3 | / | / | / | / | 1 |
| LPC-24-0406-0801-03S-IP54 | 48VAC/DC | ∅22 | 24 | 0 | 49 | / | / | / | / | 1 |
| LPC-24YT-0208-0201-01E3-04S | 0~48V AC/DC | ∅24.8 | 24 | 0 | 54.8 | 1 | / | Gigabit Ethernet | / | 1 |
| LPC-30-0316-03S-IP65 | 0~380AC/DC | ∅22 | 30 | 0 | 57.3 | / | / | / | / | 3 |
| LPC-D32-0210-26S-04SD1-01E3 | 0~24V AC/DC | ∅32 | 32 | 0 | 109 | 5 | 1 | Gigabit Ethernet、HD-SDI | RS232 | 5 |
| LPC-36-08S-05E2-IP51 | 48V AC/DC | ∅25 | 36 | 0 | 64 | 5 | / | Fast Ethernet | / | 2 |
| LPC-36-0104-0211-0202-02S-01E2 | 24V/48V AC/DC | ∅22 | 36 | 0 | 57.3 | 1 | / | Fast Ethernet | / | 2 |
| LPC-56-0104-0215-0203-02S-01E2 | 48V AC/DC | ∅25 | 56 | 0 | 85.7 | 1 | / | Fast Ethernet | / | 1 |
| LPC-56-54S | 0~28V AC/DC | ∅25 | 56 | 0 | 85.7 | / | 38 | / | RS232/ Differential | 2 |
| LPC-56-23S-02E3-01SDI-IP51 | 0~380AC/DC | ∅25 | 56 | 0 | 85.7 | 2 | / | Gigabit Ethernet、SDI | / | 23 |
| LPC-56-0415-02S-01E2-01E3-IP54 | 0~24V AC/DC | Φ105 | 56 | 0 | 103 | 2 | / | Fast Ethernet、Gigabit Ethernet | / | 2 |
| LPT012-0208-0202-06S | 0~28V AC/DC | Φ56 | 2*8A 2*2A | Φ 12.7mm | 64.4 | / | 1 | / | Encoder signal | 1 |
| LPT050-6305-04S-16GND | 220VAC/24DC | Φ160 | 60 | Φ 50mm | 339.2 | / | / | / | / | 4 |
| LPT000-0436-0410-40S-01A | 48VDC | Φ119 | 4*36A 4*10A | 0 | 113.6 | / | / | / | / | 40 |
