USB3.0 Slip Rings

These compact slip rings are specifically engineered to reliably transmit USB 3.0 signals , power, and ground between stationary and rotating structures, ensuring continuous data flow for high-speed applications like vision systems and data acquisition.

USB Slip Ring Type:USB3.0 Slip Rings
Channels:1~2
Circuits:3~10
Voltage:0~220V AV/DC
Outer Diameter(mm):∅7.6~∅25
Length(mm):19.1~85.7

USB 3.0 Slip Rings

A USB 3.0 slip ring is an electromechanical component specifically designed to transmit high-speed data and power across rotating interfaces. It enables 360° rotation while maintaining stable USB 3.0 signal integrity (5Gbps) through precision contact technology. This device effectively prevents cable winding issues, making it essential for robotics, automated machinery, medical CT scanners, and surveillance systems that require reliable high-speed data transfer during rotation.

Model List

Model Code	Voltage	Outer Diameter(mm)	USB 3.0 Channels	Circuits	Length(mm)
LPMS-01U3	0~48V AV/DC	∅7.6	1	/	19.1
LPMS-01U3-0301	0~48V AV/DC	∅7.98	1	3	22
LPM-01U3	0~110V AV/DC	∅12.8	1	/	23.5
LPM-01U3-1001-05S	0~110V AV/DC	∅16	1	10	37
LPC-01U3-0502-10S	0~220V AV/DC	∅22	1	5	57.3
LPC-02U3-0602	0~220V AV/DC	∅25	2	6	85.7
