RF Rotary Joint Integrated Slip Rings RF Rotary Joint Integrated Slip Ring High-Frequency, Multi-Channel Synchronous Rotating Transmission JINPTA Electronics

Features:

◎ Full-Spectrum Transmission: Covers DC to 67 GHz RF signals while integrating Gigabit Ethernet, CAN bus, and high-power supply in a single rotary interface for simultaneous multi-signal transmission.

◎ Ultra-Low Insertion Loss: RF-optimized shielded cavity design ensures insertion loss <0.4dB @18GHz and VSWR <1.5, guaranteeing signal integrity and transmission quality.

◎ Superior Anti-Interference: Independent isolation of RF and electrical channels with multi-layer EMI shielding eliminates crosstalk, ensuring stable performance in complex electromagnetic environments.

◎ Military-Grade Reliability: Precious metal contacts, tested for -55°C to +125°C thermal cycling, with a service life exceeding 10 million rotations for demanding applications.

◎ Compact & Lightweight: Innovative coaxial nested structure significantly saves installation space, ideal for weight- and size-sensitive applications like UAVs and robotics.

◎ Rapid Customization: Supports 12+ connector types (SMA, N, BNC, etc.) with tailored one-on-one integration solutions to accelerate project development.

RF Rotary Joint Integrated Slip Rings

JINPAT's RF-Electrical Integrated Slip Rings represent a breakthrough in rotational connectivity, combining high-frequency RF transmission (up to 67 GHz) with power and signal channels in a single compact assembly. Engineered to support Ethernet, CAN bus, and various digital protocols, these hybrid solutions deliver reliable, all-in-one transmission of data, RF signals, and power through a unified rotating interface.
Featuring ultra-low insertion loss (<0.4 dB @18 GHz), excellent VSWR (<1.5 @18 GHz), and advanced multi-layer electromagnetic shielding, JINPAT’s slip rings ensure stable, interference-free performance even in demanding conditions. Built with precious metal contacts and rigorously tested for extreme temperatures and durability, they meet the stringent requirements of aerospace, defense, radar, and high-end industrial applications.
Customizable with over 12 connector interfaces (SMA, N, BNC, and more), JINPAT provides tailored solutions for UAVs, robotic systems, test equipment, and other advanced platforms. Accelerate your integration with flexible, application-specific designs backed by expert technical support.

Customization & Professional Services

We offer comprehensive tailored solutions with flexible configurations for signal types, channel counts, protection levels, and mounting styles. Free 3D CAD models and professional technical support are available to enable rapid integration.

Can’t find a suitable model? Our 24/7 technical consulting service provides custom solutions designed for your needs.

For detailed specifications, refer to our product datasheets or contact our sales team.

Globally proven—precision-engineered for reliability in mission-critical applications.
