Video Signal Slip Rings High-Performance Video Signal Slip Rings for Flawless Rotary Transmission JINPTA Electronics

Features:

◎ Multi-Format HD Support: Fully compatible with HD-SDI, 3G-SDI, 6G-SDI, 12G-SDI, HDMI, DVI, and DisplayPort.

◎ Low Signal Degradation: Optimized for high-frequency performance with minimal insertion loss and return loss.

◎ Superior Signal Integrity: Maintains consistent 75Ω impedance for clear, distortion-resistant transmission.

◎ Hybrid Transmission: Capable of simultaneously carrying video, power, Ethernet, and control signals in a single assembly.

◎ Modular Customization: Flexible channel configurations and connector options (BNC, SMA, etc.). to meet specific requirements.

◎ Extended Service Life: Rated for millions of rotations, ensuring reliability in continuous-duty applications.

◎ Compact and Integrable: Space-saving design ideal for integration into restricted areas such as gimbals and robotic systems.

Video Signal Slip Rings

JINPAT’s Video Signal Slip Rings deliver robust and reliable transmission of high-definition video signals in

continuously rotating systems. Engineered to support a broad spectrum of video standards—including HD-SDI, 3G-SDI, 6G-SDI, 12G-SDI, HDMI, DVI, and DisplayPort—these slip rings ensure stable, high-fidelity, and interference-free video streaming in the most dynamic operating environments.

Designed with advanced signal integrity features such as low insertion loss, precise 75Ω impedance matching, and minimal return loss, JINPAT’s slip rings preserve signal quality even at high frequencies, eliminating distortion and preserving image clarity. Their modular design enables seamless integration with additional channels—such as power, control signals, Ethernet, and data interfaces—within a compact, mechanically rugged housing.

Available with industry-standard connector options including BNC, SMA, SMB, and F-type, JINPAT slip rings are built for easy installation and long-term reliability, capable of millions of revolutions under continuous operation. Ideal for broadcast camera gimbals, UAV payloads, surveillance pan-tilt units, radar electro-optical (EO) turrets, and automated inspection robots.

Customization & Services

Tailor-made slip ring solutions are available to meet your specific requirements, including custom signal types, channel configurations, protection ratings, and mechanical mounting designs. 3D CAD models and dedicated technical support are provided to facilitate seamless integration.

Can’t find an off-the-shelf solution? Our engineering team offers 24/7 technical assistance to develop optimized slip rings for your unique applications.

For detailed specifications, download our product datasheets or reach out to our sales team directly.

Engineered for Global Performance – Reliable, precision-built slip rings designed for mission-critical operations worldwide.
